1. Good quality
2. Sold well in the oversea market
3. Have CE approve
| ELECTRICAL SPEC | |||||
| output circuit | open collector NPN output | voltage output | push pull output | line driver output | |
| supply voltage | 5-24 | 5-24 | 5± 0.25 5-24 | 5± 0.25 5-24 | |
| current consumption | ≤ 80mA | ≤ 80mA | ≤ 80mA | ≤ 150mA | |
| load current | 40mA | 40mA | 40mA | 60mA | |
| single high level | min Vcc*70% | min Vcc-2.5V | min Vcc-1.5V | min 3.4V | |
| single low level | Max 0.4V | Max 0.4V | Max0.8V | Max 0.4V | |
| rising time Tr | Max 1us | Max 1us | Max 1us | Max 200ns | |
| declining time Tr | Max 1us | Max 1us | Max 1us | Max 200ns | |
| response frequency | 300kHz | 300kHz | 300kHz | 300kHz | |
| MECHANICAL SPEC | |||||
| number of pulses | starting torque without sealing | Max load permitted on shaft | shock resistance | vibration proof | |
| 2500 | ≤ 0.05Nm | radial 50N, Axial 20N | 50G /11ms | 10G 10-2000Hz | |
| rotational inertia | Working temperature | Storage temperature | Protection class | Weight | |
| 4x10 -8 kgm 2 | - 30 ~ 85 C | - 35 ~ 95 C | IP65 | 100g | |
